Chapter 7 Device Configuring Using EMS
7.9.1

Selecting Low Delay Mode

To select Low Delay mode:
1. Select the Decoding Channel in the Multiplex & Decoding Output box.
2. Click Properties on the toolbar.
The Decoding Channel Properties dialog displays.
3. Select the Video tab.
4. Select Low Delay for Buffer Management in the Advanced box, see Figure 7–33.
Low Delay option
5. Click Apply.
© 2012 Harmonic Inc.
Figure 7–33: Selecting Low Delay Mode
144
Low Delay Mode
ProView 7000 v.2.6, Rev. E
