Walker Evans Fts 7043234; Ryde Fx Fts 7043244; Fox Fts 7043142; Ryde Fx Fts 7041975 - Polaris 2007 Two Stroke Service Manual

Walker Evans FTS 7043234

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth
Shaft PN (assembly)
Pressure*
Spring
Spring Ratio
Free Length
Fluid*
*= Critical specifications

Ryde FX FTS 7043244

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth
Shaft PN
Pressure
Spring
Spring Ratio
Free Length
Fluid
Spring Installed Length
NOTE
12.49" (317.2mm)
8.92" (226.6mm)
3.57" (90.7mm)
1.124" (28.5mm)
N/A
1800228
215psi/14.8 bar
N/A
N/A
N/A
70 cc / 5 wt.
NOTE
12.12" (307.9mm)
8.61" (3.52mm)
3.52" (89.3mm)
.50" (12.7mm)
4.68" (118.9mm)
1700026
200 psi (13.8 bar)
7043147
130/270 lb/in
8.22" (209mm)
107cc
7.72" (196mm)
REAR SUSPENSION

Fox FTS 7043142

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth measured
from the bottom of the
shock body
Shaft PN
Pressure
Spring
Spring Ratio
Free Length
Fluid

Ryde FX FTS 7041975

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth from the top of
the shock body
Shaft PN
PSI
Spring
Spring Ratio
Free Length
Fluid
NOTE
12.51" (317.8mm)
8.92" (226.6mm)
3.59" (91.2mm)
.50" (12.7mm)
.84" (21.3)
1500713
200psi/13.8bar
7042050
170 lb/in
7.50" (191mm)
Full
NOTE
12.10" (307.3mm)
8.60" (218.4mm)
3.5" (89mm)
.50" (12.7mm)
4.61" (117mm)
1700026
200 psi (13.8 bar)
7041914
160 lb/in
7.57
102cc
9.27
9
