Fox Rts 7043266; Fox Rts 7043177; Walker Evans Rts 7043235; Fox Rts (M-10) 7043216 - Polaris 2007 Two Stroke Service Manual

Fox RTS 7043266

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth
Shaft PN
PSI
Apply primer N and Green
Body Cap Loctite 638
Torque to75 ft-lb (102 N-m)
Apply primer N and Red
Rod Eyelet Loctite 277
Torque to 30 ft-lb (41 N-m)
Banjo Bolt Torque to 15 ft-lb (20 N-m)

Fox RTS 7043177

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth
Shaft PN
PSI

Walker Evans RTS 7043235

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth
Shaft PN
PSI
Fluid
NOTE
15.65" (39.75cm)
10.56" (26.2cm)
5.09" (12.9cm)
.50" (1.27cm)
1.63" (4.1cm)
1500779
200 psi (13.8 bar)
NOTE
15.60" (39.6 cm)
10.56" (26.2 cm)
5.04" (12.8 cm)
.50" (1.27 cm)
1.22" (3.1 cm)
1500599
200 (13.8 bar)
NOTE
16.71" (42.4 cm)
10.96" (27.8 cm)
5.75" (14.6 cm)
.50" (1.27 cm)
7.25" (18.4 cm)
1800296
200 (13.8 bar)
Walker Evans 5 wt
REAR SUSPENSION

Fox RTS (M-10) 7043216

ITEM
Extended Length
Collapsed Length
Stroke
Shock Rod
IFP Depth
Shaft PN
PSI
7042206 (425 lb/in 7.6 kg/mm)
Spring (Spring Ratio) 7042207 (273 lb/in 4.9 kg/mm)
7042208 (715 lb/in1.8 kg/mm)
Free Length
NOTE
14.12" (35.9 cm)
9.29" (23.6 cm)
4.83" (12.3 cm)
.50" (1.27 cm)
2.40" (6.1cm)
1500562
300 psi (20.6 bar)
7042206 (6.20" / 157 mm)
7042207 (5.40" / 137 mm)
7042208 (6.20" / 157 mm)
9.29
9
