500/600 (Carbureted) Engine Disassembly - Polaris 2007 Two Stroke Service Manual

ENGINE

500/600 (Carbureted) Engine Disassembly

1
2
22 ft-lb
(30 N-m)
LOCTITE® 242
3
70 in-lb
(7.9 N-m)
4
9 ft-lb
(12.2 N-m)
5
6
9
10
11
12
18 ft-lb
(24 N-m)
13
14
15
32 ft-lb
(43 N-m)
16
5.22
7
8
14
23
29
28
30
500 Liberty Engine Shown
17
18
19
If NEW
Height Installation
see page 5.5
20
21
22
26
25
24
27
31
See Torque sequence
on page 5.22
