Suspension Spring Pre-Load/Installed Length

When installing springs on shocks the specifications will call out "Installed Length" or "Pre-Load".
Installed Length is the length of the spring from end to end when it is ready to be installed on the snowmobile. You should adjust
the spring preload ring until you reach your specified spring installed length.
2
Pre-Load is the amount of space that you have from the bottom of the spring preload adjuster to the top of the spring retainer.
Preload
Installed Length
