CHASSIS & HOOD

HANDLEBAR COVER

HANDLE BAR COVER REMOVAL/
INSTALTION
1. Slide handle bar covers slide (A) off on each side.
2. Remove the handle bar cover darts (B) on each side.
3. Remove handle bar cover (C).
4. Installation is in reverse order of removal.

SKIS

SKI REMOVAL

1. Securely lift the front of the machine off the ground.
2. Remove the ski to spindle bolt and washers.
3. Remove ski, bushing and ski bumper.

SKI INSTALLATION

1. Place ski, bushing and bumper onto spindle.
2. Insert the ski to spindle bolt through the ski and spindle.
NOTE: The ski bumper is orientated so that the
"FRONT" label is installed toward the toe of the ski.
3. Tighten the nuts.
10.8
C
B
A

NOSEPAN

REPLACEMENT

IMPORTANT: When
nosepan, the open circles represent rivets installed
from inside the nosepan through the bottom. The
filled in circles represent rivets installed from the
under side of nosepan through to the top.
NOTE: Rivet holes may require drilling into the
bulkhead. When transfer drilling holes do not force
the nosepan into a position which is not uniform to
the other side. Rivet holes across from each other.
installing a replacement
