600 / 700 HO CFI ENGINE

600/700 CFI Engine Removal

NOTE: Inspect all parts for wear or damage during
disassembly. Replace all seals, o-rings, and gaskets
with Genuine Pure Polaris parts during assembly.
1. Remove the side panels. See "SIDE PANELS" on
page 10.2.
2. Disconnect the battery ground (-) cable from the battery if
equipped.
3. Unplug exhaust temperature sensor and remove the exhaust
system.
4. Remove the spark plug leads from the spark plugs.
5. Remove the belt cover/electrical center cover (1).
1
6. Disconnect the intake air sensor (2) located on the MAG
side of the airbox.
2
7. Remove the return fuel line "P" holder (3) located on the
MAG side of the airbox.
8. Separate the fuel filter from the filter clip (4) that is on the
MAG side of the airbox.
3
9. Remove the airbox (5) by pulling it straight out from the
air box adapter (6).
6
10. Disconnect the main harness (7) at the ECU. This is the
smaller of the two plugs located on the ECU. Remove it by
pressing up on the underside of the plug and pulling straight
off.
11. Disconnect the regulator rectifier connections (8).
ENGINE
4
5
7
5.29
