18. Remove all coolant hoses from the coolant bottle and
secure the loose hoses out of the way for engine removal.
19. Remove the four right hand chassis brace fasteners and
remove the brace (13) from the chassis.
20. Drain the oil from oil tank.
21. Remove the oil tank fasteners (14) that hold the top of the
oil tank to the chassis.
22. Disconnect the oil supply line (15) from the oil tank, located
at the bottom portion of the oil tank. Plug and secure the
loose oil line so that it can come out with the engine.
14
23. Remove the engine isolator (16) and rear torque stop (17)
located on the left hand side of the engine.
16
13
15
17
24. Remove the four engine mounting fasteners (18) located on
the engine straps.
25. Remove the Schrader valve cover located under the
steering hoop (19), and depressurize the fuel rail. See "Fuel
Rail Bleeding" on page 4.20.
19
26. Using the fuel line disconnection tool (PN PS-47152) (20),
separate the fuel filter (21) and the fuel return line (22).
21
20
27. Secure the loose fuel lines out of the way for engine
removal.
NOTE: A helper will be needed for the following
steps.
ENGINE
18
5
600
22
5.31
