CHASSIS & HOOD

SIDE PANELS

Side Panel Removal

1. Grab the upper portion (1) of the panel and lift straight upwards and out toward you. This will lift it over the tab that is located
on the console.
2. Lift the lower portion up and out until the tabs (2) can be released from the fender (4).
3. Pull the panel straight out to release the hinge tabs (3) from the fender.
4. Remove panel.

Side Panel Installation

1. Insert the hinge tabs (3) into the front portion of the fender (4).
2. Close the panel and lift just slightly to insert the lower tabs (2).
3. Push in the top portion (1) so that the console tab can be inserted into the panel.
4. Push the panel into place.
5. If lower tabs are not inserted, lift up panel and try again.
10.2
3
4
1
2
