ENGINE
20. Move the hose clamp (7) and remove and secure it out of
the way.
21. Remove the coolant supply hose that is located at the
bottom of the coolant bottle and secure it out of the way.
This will come out with the engine.
22. Remove the rear (9) and left (10) motor mount nuts located
on the right hand side of the engine.
9
RH Rear
23. Remove the left hand rear torque stop fasteners (11)
5.20
24. Remove the inside motor mount fastener (12), located
7
25. Remove the rear torque stop plate.
26. Remove the engine isolator limiter assembly fasteners (13)
10
RH Front
27. Remove the LH front motor mount nylock nut (14) and
11
28. Remove the LH nose pan plug located on the nose pan next
under the PTO carburetor boot.
12
and then remove the torque stop assembly.
13
washer.
14
to the shock tower. This will allow access to the front
fasteners for the LH chassis brace.
