CLUTCHING

Final Gearing

The final drive gear ratio plays an important role in how much vehicle load is transmitted back to the helix. A tall gear ratio (lower
numerical number) typically results in lower initial vehicle acceleration, but a higher top-end vehicle speed. A lower gear ratio
(higher numerical number) typically results in a higher initial vehicle acceleration, but a lower top-end vehicle speed.
Choosing the proper gear ratio is important to overall drive system performance. When deciding on which gear ratio to use, the
operator must factor in the decision where the snowmobile will be ridden, what type of riding will be encountered, and the level of
performance the operator hopes to achieve.
Gearing a snowmobile too low for extended high-speed runs may cause damage to the drive belt and drive system, while gearing
a snowmobile too high for deep-snow, mountain use may cause premature belt and clutch wear.
Typically, it is recommended to gear the snowmobile with a slightly higher ratio than the actual top speed the snowmobile will ever
achieve.
1:1 Shift Ratio
A 1:1 shift ratio occurs when the drive clutch and the driven clutch are rotating at the same RPM.
The mathematical vehicle speed for a given gear ratio at a 1:1 shift ratio is represented in the chaincase gearing charts located in the
Final Drive Chapter.

Low / High Ratio

Low ratio is the mechanical position when the drive belt is all the way down into the drive clutch, and all the way out on the driven
6
clutch. High ratio represents when the drive belt is all the way out on the drive clutch, and all the way in on the driven clutch.

Driven Helix / Ramp

The helix cam is the primary torque feedback component within the driven clutch, regardless of driven clutch type. The beginning
angle of the helix must transmit enough torque feedback to the moveable sheave in order to pinch the drive belt while minimizing
belt slip. The flatter or lower the helix angle, the more side force will be exerted on the moveable sheave, while the steeper, or higher
the helix angle, the less side force will be exerted on the moveable sheave.
6.3
