Rear Suspension Rear Track Shock (RTS)
Stock Valving
SHOCK PN 7043177
1.125x.093
.900x.010
1.000x.010
1.100x.012
1.100x.010
1.100.008
1.000x.006
1.300x.008
1.300x.008
Piston Orifice .093
1.250x.010
1.250x.010
1.100x.012
1.000x.012
.900x.012
.800x.012
.620x.093

SHOCK VALVE PART NUMBERS

Shock valves are used in a stack on the top and on the bottom of
the shock piston. These stacks can be adjusted so that it can
control the amount of fluid that is forced by as the piston travels
through its motion. Below is a chart that has the part numbers of
these valves, proceeding the part number is the size of the
washer (out side diameter x thickness). A thick washer (.700 x
.010) will try to keep the fluid from passing through the piston
as it travels.
Refer to the appropriate parts manual for a complete listing of
shock parts.
7043246 7043266
1.125x.093
.700x.015
.700x.015
.700x.015
.700x.015
.700x.015
.700x.015
.900x.010
1.000x.010
1.000x.008
1.100x.012
1.100x.008
1.250x.012
1.250x.010
.800x.008
.900x.010
1.250x.008
1.250x.008
1.300x.008
1.300x.006
.070 .076
1.250x.008
1.250x.008
.700x.008
.700x.006
1.100x.012
1.100x.015
1.000x.010
1.100x.015
.900x.008
.900x.008
.800x.008
.950x.050
.950x.050
.950x.050
.950x.050
Piston Assy
REAR SUSPENSION
7043205 7043216
.875x.090
.625x.065
.700x.008 1.125x.093
.800x.008 .900x.008
.900x.010 1.300x.008
1.000x.010 1.300x.008
1.100x.008 1.300x.010
.900x.008 .800x.010
1.100x.008 1.300x.006
.700x.010 1.300x.008
1.250x.010
1.300x.010
.082 .055
1.250x.012
.800x.008
1.100x.010 1.250x.012
1.000x.010 1.100x.010
.900x.010 1.125x.093
.800x.010 .620x.093
.700x.010
.625x.065
1.100x.025
1.000x.015
1.100x.015
.700x.010
.875x.090
7043235
.625x.065
.700x.010
.800x.010
.900x.010
1.000x.010
1.100x.010
1.250x.012
.040
1.300x.010
1.250x.010
1.100x.008
1.100x.008
1.000x.010
.900x.010
.800x.008
.700x.010
.875x.090
9
9.23
