5-3
Option Installation
Installation
Perform the following steps to install the Redundant Power Supply option in a
ProLiant Storage System /U.
1.
Loosen the thumbscrew securing the blank panel over the lower power
supply opening and remove the panel.
TROJ044.EPS
Figure 5-1. Removing the blank power supply panel
IMPORTANT: Remove the protective cover from the power supply
connector.
2.
Depress the latch and pivot the handle on the Redundant Power Supply
to the fully open position.
3.
Align the power supply with the rail in the power supply opening and
push the supply in as far as it will go.
Compaq ProLiant Storage System /U User Guide
