5-17 Option Installation
8. Tower system:
a.
b. Place the serial label on the drive cage and the model label on the
c.
Rack system:
a.
b. Place the serial label on the drive cage and the model label on the
c.
9. Install the new Single Bus I/O board supplied in the option kit.
10. Replace the fan module.
11. Replace the power supply(s).
12. Replace the power cord(s).
13. Install the drives and blank drive panels in the appropriate locations.
14. Connect the SCSI Bus port on the Single Bus I/O board to the
SCSI controller using the SCSI cable provided.
15. Turn ON the storage system.
16. Turn ON the server supporting the storage system.
17. Run the Compaq System Configuration Utility to recognize the new drive
configuration.
18. Place the Dual Bus drive cage, I/O board, and Quick Installation
Instructions in the Single Bus option shipping container to save and protect
them for possible future use.
Installation of the Single Bus Conversion option is complete.
Replace the 12 screws to secure the front panel to the chassis.
front panel so that they cover the old labels.
Replace the front door.
Replace the 8 screws to secure the front panel to the chassis.
front panel so that they cover the old labels.
Tighten the two thumbscrews to secure the storage system in
the rack.
