5-10
Option Installation
5.
Tower system:
a.
b. Remove the 12 screws marked with a
c.
TROJ028.EPS
Figure 5-6. Removing the drive cage from a tower system
Open the front door and remove it by lifting up.
to the chassis
Carefully slide the drive cage from the chassis.
securing the front panel
Compaq ProLiant Storage System /U User Guide
