1-4
Introduction to the ProLiant Storage System /U
Front Panel Features
Figure 1-3 shows the front panel controls accessible to the user. The rack
model has the status indicators and power switch, but no plastic door.
Figure 1-3. Front panel features (tower model shown)
TROJ004.EPS
Status Indicators
Power Switch
(behind sliding door)
Keylock
Compaq ProLiant Storage System /U User Guide
