Introduction to the ProLiant Storage System /U
Rear Panel Features
Figure 1-4 shows the features and accessible components on the
ProLiant Storage System /U rear panel.
TROJ005.EPS
Redundant Power
Figure 1-4. Rear panel features (ProLiant Storage System Model U1 shown)
Power Supply
I/O Board
Fans
Blank Panel
Supply Bay
CAUTION: In a single power supply configuration, make certain that the
Redundant Power Supply Cover Plate remains in place to maintain thermal
integrity within the storage system.
Compaq ProLiant Storage System /U User Guide
