Installation of ProLiant Storage System /U
Recovery Server Systems
See Figure 2-13 for an illustration of cable connections in a Recovery Server
installation. For more detailed explanations of this type of system, refer to the
Recovery Server Option User Guide that is supplied in the Recovery Server
Option Kit.
Figure 2-13. Cable connections in Recovery Server systems
To SCSI
Controller in Server 2
To SCSI
Controller in Server 1
TROJ047.EPS
Compaq ProLiant Storage System /U User Guide
