5-12 Option Installation
8. Tower system:
a.
b. Place the serial label on the drive cage and the model label on the
c.
Rack system:
a.
b. Place the serial label on the drive cage and the model label on the
c.
9. Install the new Dual Bus I/O board supplied in the option kit.
10. Replace the fan module.
11. Replace the power supply(s).
12. Replace the power cord(s).
13. Install the drives and blank drive panels in the appropriate locations.
14. Connect the Bus 1 port on the Dual Bus I/O board to SCSI controller 1
using the SCSI cable provided.
15. Connect the Bus 2 port on the Dual Bus I/O board to SCSI controller 2 .
using the SCSI cable provided.
16. Turn ON the storage system.
17. Turn ON the server(s) supporting the storage system.
18. Run the Compaq System Configuration Utility to recognize the new
drive configuration.
19. Run the Compaq Array Configuration Utility (if appropriate) to
configure the drives into an array.
20. Place the Single Bus drive cage, I/O board, and Quick Installation
Instructions in the Dual Bus options shipping container to save and
protect them for possible future use.
Installation of the Dual Bus Conversion option is complete.
Replace the 12 screws to secure the front panel to the chassis.
front panel so that they cover the old labels.
Replace the front door.
Replace the 8 screws to secure the front panel to the chassis.
front panel so that they cover the old labels.
Tighten the two thumbscrews to secure the storage system in the
rack.
Compaq ProLiant Storage System /U User Guide
