3-5
Operation
Recovery Server I/O Board
These indicators apply to only the Recovery Server I/O option board.
TROJ039.EPS
Figure 3-4. Recovery Server I/O board status indicators
Indicator
Server 1
Server 2
Table 3-4
Recovery Server I/O Board Status Indicators
Condition
Green
Off
Green
Off
Server 2
Server 1
Meaning
Server 1 is connected to the drives
Server 1 is not connected to the drives
Server 2 is connected to the drives
Server 2 is not connected to the drives
Compaq ProLiant Storage System /U User Guide
