Installation steps

Carry out the following steps to install the system:
FIRST, read the safety and precaution information on page 14 carefully.
SECOND, mount the Main Equipment as detailed in the section starting on page 18.
THIRD, install the CO line, T1/PRI Module and Expansion Modules as required.
An Expansion Module must be installed if the following is required:
•
More than 8 extensions
•
More than four CO lines
An IP Router Module must be installed if an internal LAN or connection to a DSL Line or Cable Modem is
required. It must also be fitted if VoIP trunks are to be provided. The IP Router is supplied in two variants, one
with two and the other with twelve VoIP trunks.
A Voice Module must be installed to provide Voice Mail, Customized Courtesy Service, Directory Service or
Auto-Attendant functionality.
The Battery Back Up module and battery must be installed if battery back up is required.
FOURTH, cable the extensions to the Main Equipment and install the system digital telephone sets and
standard telephones as detailed in the Cabling Section starting on page 44. This section also covers
installation of the following:
• Door Phone
• Doorstrike
• External Music-On-Hold
• Public Address
• RS232 Interface to provide Call Logging
FIFTH, cable the CO line connections as detailed in the cabling section starting on page 44.
SIXTH, Power up the system and provide customer training as detailed on page 125.
