To Program the Line selection Method
1.
From the programming extension, press the PROGRAM key.
2.
Press the Scroll Down key (î) until "System Programming" is displayed.
3.
Select "System Programming".
4.
Enter the System Programming Password and select "Lines".
5.
Press the Scroll Down key (î) until "Outgoing Groups" is displayed.
6.
Select "Outgoing Groups".
7.
Select the Group
8.
Select either "Linear" or "Distributed".
A "♦" indicates the programmed option
The default is "Linear".
To Program Lines into Groups for Access using the Codes 9 or 760 - 769
CO lines can be grouped together in up to 11 outgoing groups. Each outgoing group is associated with a code.
These codes are 9 or 760 - 769, with group 1 being associated with 9, etc. Dialing a code selects a line from the
associated outgoing group.
1.
From the programming extension, press the PROGRAM key.
2.
Press the Scroll Down key (î) until "System Programming" is displayed.
3.
Select "System Programming".
4.
Enter the System Programming Password and select "Lines".
5.
Press the Scroll Down key (î) until "Outgoing Groups" is displayed.
6.
Select "Outgoing Groups".
Select the group you wish to set up.
7.
Select either "Linear" or "Distributed".
8.
9.
Select the lines to be in the group. The lines in the group are indicated by a "♦".
NOTE: Lines can be in one outgoing group only. Selecting a line to be a member of a group automatically
removes it from all other groups.
NOTE: VoIP trunks are in outgoing group 2 in default. The group is selected by dialing 760.
To Program PBX Access Digits
1.
From the Programming extension, press the PROGRAM key.
2.
Press the Scroll Down key (î) until "System Programming" is displayed.
3.
Select "System Programming".
4.
Enter the System Programming Password and select "Lines".
5.
Press the Scroll Down key (î) until "PBX Group" is displayed.
6.
Select "PBX Group".
7.
Select which group you wish to use. You are then presented another menu with which to program the parent
PBX Access digits.
•
Select "Set/Clear PBX Status" to set or clear the selected outgoing group as a PBX group. A
confirmation prompt appears momentarily on the top line of the display.
•
Select "Access Digits". Enter the "Access Digits" for an external line on the parent PBX and select
"Confirm".
•
Select "Ext. Num. Length". Enter the number of digits in the extension numbers on the parent PBX.
Press the speakerphone key to finish programming.
Least-Cost Routing (LCR)
This is a relatively simple implementation of LCR. Up to 50 codes of five digits can be programmed. Each of
these codes can be substituted with a code of up to 9 digits if a different carrier is to be selected for the dialed
code. Alternatively the code can be used to route the call over a particular line. Two timebands can also be
associated with the feature so the option to route the calls using the substitute codes or the alternative lines can be
automatically activated at two different times in a 24 hour period.
Installation and Maintenance Manual
EncoreCX
105
