Essential Programming
Essential programming is carried out either from a digital telephone set connected to extension 20 or via the
Programming and Maintenance software on the programming PC.
Ensure that the following programming is done.
Equipped CO lines
The system assumes that all line cards have lines connected to them. If lines are not connected, it is vital to
unequip these lines in system programming, as follows:
1.
From the programming extension, press the phone programming key and
select "System programming".
2.
Enter the PIN and select "Lines".
3.
Select "Equipped Lines".
4.
Select the lines you want to equip.
Equipped lines are denoted by ♦. Unequipped lines are denoted by ?.
5.
6.
Press the speakerphone key to finish programming.
Incoming ringing
The phones to be rung for incoming calls are programmed as follows:
1.
Select "Lines".
2.
Select "Incoming Ringing".
3.
Select the line.
4.
Select "Day Mode", "Night Mode" or "Day and Night Mode".
5.
Select whether the line is to ring an extension or Group. If the line is to be presented to the Auto-Attendant
or Courtesy Service, it is selected here.
Note that the first eight extensions are in group 1 as default. To change the extensions in a Group, select "Lines"
and then "Group Programming".
Call restriction
Extensions are entered into different Classes of Service for restriction purposes. There are six Classes of Service
selected under "Extension" programming. There are also four tables of codes selected in "System" programming
which determine additional codes that are restricted or allowed.
1.
Select "Extensions"
2.
Select "Restriction classes".
3.
Select "Day Class of Service" or "Night Class of Service".
4.
Select the class and enter the extensions.
Class 1 is no calls restricted.
Class 2 restricts codes added to Table 2 in Class codes programming.
Class 3 restricts codes in Tables 2 and 3 in Class codes programming.
Class 5 is associated with extensions when codes entered in the "Allowed Table" in Class codes programming are
to be allowed. This is combined with Classes 2 and 3.
Class 6 is the additional restriction codes in the "Restricted Table" in Class codes programming. These can be
combined with Classes 1, 2 and 3.
Installation and Maintenance Manual
EncoreCX
67
