Summary of Contents for Inter-Tel EncoreCX

  • Page 2: Table Of Contents

    EncoreCX Internet Module Manual Table of Contents TABLE OF CONTENTS ........................1 INTRODUCTION ..........................2 .............................2 EATURES CONNECTING TO THE ENCORECX PROGRAMMING AND MAINTENANCE SOFTWARE ............................3 RESETTING THE INTERNET MODULE..................4 INSTALLATION WIZARD........................4 PC SETTINGS............................6 USING THE INTERNET ........................6 LOCAL AREA NETWORK .........................6 WIDE AREA NETWORK ........................6...

  • Page 3: Introduction

    Internet Module Manual Introduction The Internet module is an EncoreCX system module that provides multi-user high-speed Internet access using a Digital Subscriber Line (DSL) or Broadband. It also provides a Local Area Network that allows users to network PCs and share printers and other resources within the office. It is easy to install and manage using the installation wizard and management system.

  • Page 4: Connecting To The Encorecx Programming And Maintenance Software

    EncoreCX Internet Module Manual Connecting to the EncoreCX Programming and Maintenance Software · Select Connect on main screen. The following screen is displayed. · Select Connect on pop-up screen. · Select Internet Module. The following screen is displayed. · Installation Wizard takes you to the Installation Wizard screen.

  • Page 5: Resetting The Internet Module

    Back takes you back to the previous screen. For some configuration changes to take effect, a warm reset must be performed on the Internet module. A prompt will appear on the EncoreCX Programming and Maintenance software screen requesting a reset.
  • Page 6 EncoreCX Internet Module Manual The following procedure is now used to set up Internet access. · Select Installation Wizard on the main screen. The following screen is displayed. · Select DSL/Broadband. The following screen is displayed. · Enter the Username. This will be provided by the ISP.

  • Page 7: Pc Settings

    EncoreCX Internet Module Manual PC Settings Each PC used to browse the Internet must be configured to obtain an IP address automatically. · Right click Network Neighborhood. · Left click Properties. · Select Protocols tab. · Scroll through protocols listed and highlight TCP/IP Protocol and click the properties tab.

  • Page 8: Dsl

    EncoreCX Internet Module Manual DSL provides "always on" service, meaning the Internet module is permanently connected to the Internet using a standard telephone line. The telephone line is terminated at the user end by a splitter that provides a normal telephone connection as well as a high-speed data connection.

  • Page 9: Dsl/Broadband Profile

    EncoreCX Internet Module Manual DSL/Broadband Profile While the installation wizard provides a simple method of setting up the Internet module using the minimum number of settings, the profile settings provide the user with the ability to assign static IP addressing and access to Timebands to control Internet access.
  • Page 10 EncoreCX Internet Module Manual · Select DSL/Broadband Profile on the WAN Setup screen. The following screen is displayed. · Enter the Username assigned by the ISP to allow access to the Internet. The username can be up to 60 alphanumeric characters long.

  • Page 11: Timebands

    EncoreCX Internet Module Manual Timebands The following procedure is used to program timebands. · Select Apply Timebands on the DSL/Broadband Profile screen. The following screen is displayed. · Set on-time 1 (hh:mm) for day of week. · Set off-time 1 (hh:mm) for day of week.

  • Page 12: Dhcp Server

    EncoreCX Internet Module Manual DHCP Server The Dynamic Host Configuration Protocol (DHCP) server automatically assigns IP addresses to each host on the LAN. It also provides the default gateway address, primary and secondary Domain Name System (DNS) server address, and primary and secondary Windows Internet Naming Service (WINS) server addresses.
  • Page 13 DNS Relay Enabled - this box is checked by default. · Click Save. · Click Send. · For the changes to take effect, press RESET when prompted on the main screen of the EncoreCX Programming and Maintenance software or press the reset button on the Internet module MDF.

  • Page 14: Firewall

    EncoreCX Internet Module Manual Firewall A firewall is used to restrict access between the internal LAN and the Internet. The firewall consists of packet filters, which are used to control the flow of traffic between the internal LAN and the Internet.

  • Page 15: Filters

    EncoreCX Internet Module Manual Filters A filter stack comprising of up to 16 filters can be defined for outgoing and incoming traffic. Each filter contains fields whose contents are compared to every IP packet passing through the firewall. If the contents of any field match the corresponding information in an IP packet, the packet is either blocked or allowed to pass through to the next filter in the stack.

  • Page 16: Incoming Traffic Filters

    EncoreCX Internet Module Manual · Source Netmask This is used in combination with the source address field to specify a network address and compare it with the network address of the IP packets. · Destination IP Address The filter compares the destination address of the IP packets with the address specified in this field ·...
  • Page 17 EncoreCX Internet Module Manual · Prot (Protocol) This field defines a protocol and has a drop-down menu with four items. ALL - the filter operates on packets which contain the UDP, TCP or ICMP protocols. UDP - the filter operates on packets which contain the UDP protocol.

  • Page 18: Statistics

    EncoreCX Internet Module Manual Statistics Statistics relating to data traffic on the Internet module are available. · Select Statistics on the LAN Setup screen. · The following screen is displayed. · RESET sets all counters to zero. LAN Statistics The LAN statistics provide performance information about data between the LAN and the router.
  • Page 19 EncoreCX Internet Module Manual In Errors The number of inbound (1) Faulty NIC on LAN host. packets that contained errors at the MAC layer preventing (2) Collisions on LAN. them from being delivered to a higher-layer protocol. Operational Status Indicates the state of the LAN interface.

  • Page 20: Icmp Statistics

    EncoreCX Internet Module Manual ICMP Statistics Internet Control Message Protocol generates error messages and performance information to indicate problems in delivering IP packets between LAN hosts and the router. Statistic Description Possible causes InMessages The total number of ICMP Bursts at high levels indicate some messages received from the problem on the LAN.
  • Page 21 EncoreCX Internet Module Manual OutRedirects Sent by the router to a LAN On a LAN with a subnet, a LAN host is host to suggest a better or sending packets to the wrong gateway alternative LAN default because it's default gateway setting is gateway.

  • Page 22: Specifications

    EncoreCX Internet Module Manual Specifications 4 x 10/100 Base-T switched Ethernet ports, autosensing, auto MDI/MDI-X 10 Base-T port for external DSL or Cable modem PPPoE, Dynamic IP, Static IP supported Protocols IP V4, TCP, UDP, ICMP Authentication Automatic PAP/CHAP negotiation...
  • Page 23 EncoreCX Internet Module Manual...
  • Page 24 EncoreCX Internet Module Manual Issue 1, October 2003 Part number 618.5044...
