Audio Cable - Polycom VSX Series Integrator's Reference Manual

Audio Cable

Description
Dual RCA connectors (red/white)
on both ends
RED
WH
© Polycom, Inc.
This cable connects a VSX system to an external audio system.
Used With
VSX 7000
VSX 8000
RED INSULATION (2X)
WHITE INSULATION (2X)
6 IN. ± 0.5 IN.
(2X)
RED
WHT
WIRING DIAGRAM
This drawing is provided for design reference only. Polycom claims no responsibility or
liability for the quality, performance and/or reliability of cables based on this reference
drawing. Cables are available from Polycom that meet the appropriate manufacturing
tolerances, quality and performance parameters.
Part Number
2457-09212-001
OVER MOLD "RCA" CONNECTORS
25 FEET +/- 3"
RED
WHT
Chapter 1 - Cables
Length
Shipped Length: 25 ft (7.6 m)
Maximum Approved Length:
100 ft (30 m)
RED
WH
1 - 23
