Controls and Functions
Handset Phone Controls and Functions
11
10
9
8
7
6
5
Figure 49. Phone Features on the Handset
1. Headset Jack
2. Soft Key – Changes functions based on menu navigation; active function shown on display above key; Main Display – MENU function allows
menu navigation
3. SPKR – Activates speaker phone
4. # – Access to telephone answering system (retrieve messages)
5. * – Pressing * prior to redialing from recent call list adds a 1 for long distance
6. MUTE – Mutes call
7. Scroll Button (Up/Down) – Navigates menus, adjusts volume, accesses recent calls
8. Message LED – Indicates new message waiting
9. TALK/END – Initiates/ends calls and provides menu exit
10. Soft Key – Changes functions based on menu navigation; active function shown on display above key; Main Display – PHNBK function retrieves phone book
entries
11. Handset Earpiece
[71]
U S I N G Y O U R T E L E P H O N E S Y S T E M
1
2
3
4
