Install Motion Sensor
1. Remove the Motion Sensor and related components from the box and physically install the device
according to the manufacturer's printed instructions
2. Once the Motion Sensor has been mounted to a flat surface and installed according to the
manufacturer's recommendations, move to the next step
Add the Motion Sensor to the LifeShield System
Starting with the Motion Sensor attached to a flat surface:
1. On the Handset or Console, press MENU
2. Scroll to Security Setup, press SELECT and enter the Master Code
3. Scroll to Sensors, press SELECT
4. Scroll to <Add New>, press SELECT
5. Scroll to Motion, press SELECT
6. Following the instructions displayed on the LCD screen, wait 5 seconds then detach (remove) the
Front Cover of the Motion Sensor as illustrated in the manufacturer's printed instructions ("Un-clip
Sensor from Bracket"). (You will have 30 seconds to complete this step.)
When the Motion Sensor has successfully been added you will hear 4 fast confirmation beeps from the
LifeShield system. If there are no confirmation beeps, check to make sure that the battery insulator tab
has been removed, re-attach the Front Cover and repeat the steps above.
Once the Motion Sensor has been added to the LifeShield system:
7. Use the Edit feature to rename the device (if desired). Press DELETE to erase text and use the key-
pad to type a new name.
8. Press OK, then press BACK until the Main Menu is displayed
9. Re-attach the Front Cover of the Motion Sensor
Test the Motion Sensor
1. Move away from the area that is in direct line of sight of the Motion Sensor (move to an adjacent room). Wait 3 minutes.
2. On the Handset or Console, press MENU
3. Scroll to Utilities, press SELECT
4. Scroll to Test, press SELECT
5. Enter your Master Code
6. Select System Test
7. Press the SKIP soft key to skip the Siren Test
8. Press the OK soft key on next screen for Starting Comm Test
9. Scroll to the name of the Sensor that you would like to test, and press SELECT
10. Move back into the line of sight of the Motion Sensor (this will trigger the device).
If the Motion Sensor test is successful, the LCD screen will display "Sensor xxx Passed." If these words do not appear, return
to "Add the Motion Sensor to the LifeShield System."
[www.LifeShield.com]

Installing the Motion Sensor

I N S T A L L I N G Y O U R S E C U R I T Y S Y S T E M
!
NOTE: It is important to follow the
manufacturer's printed instructions
regarding (a) battery installation
and activation, (b) setting adjust-
ment, (c) mounting and installation
and (d) range adjustment (walk
test) prior to moving on to the next
step involving integration of this
device with your LifeShield system.
Please note that it is not necessary
to "PROGRAM" the device at
this time.
i
If you require additional
assistance with setup or
installation, please contact
LifeShield Customer Support at
1-888-392-2044.
