Install Smoke Sensor
1. Remove the Smoke Sensor and related components from the box and physically install the device
according to the manufacturer's printed instructions.
2. Once the mounting bracket is secured to the ceiling, attach the Smoke Sensor into it.
Add the Smoke Sensor to the LifeShield System
Starting with the Smoke Sensor attached to the mounting bracket:
1. On the Handset or Console, press MENU
2. Scroll to Security Setup, press SELECT and enter the Master Code
3. Scroll to Sensors, press SELECT
4. Scroll to <Add New>, press SELECT
5. Scroll to Smoke Sensor, press SELECT
6. Following the instructions displayed on the LCD screen:
Wait 5 seconds then detach the Smoke Sensor from the mounting bracket ("Un-clip Sensor from
bracket"). (You will have 30 seconds to complete this step.)
When the Smoke Sensor has successfully been added you will hear 4 fast confirmation beeps from the
LifeShield system. If there are no confirmation beeps, check to make sure that the battery insulator tab
has been removed, re-attach the Smoke Sensor to the mounting bracket and repeat the steps above.
Once the Smoke Sensor has been added to the LifeShield system:
7. Use the Edit feature to rename the device (if desired). (Press DELETE to erase text and the keypad
keys to type new ones).
8. Press OK, then press BACK until the Main Menu is displayed
9. Re-attach the Smoke Sensor to the mounting bracket
Test the Smoke Sensor
1. On the Handset or Console, press MENU
2. Scroll to Utilities, press SELECT
3. Scroll to Test, press SELECT
4. Enter your Master Code
5. Select System Test
6. Press the SKIP soft key to skip the Siren Test
7. Press the OK soft key on next screen for Starting Comm Test
8. Scroll to the name of the Sensor that you would like to test, and press SELECT
9. On the Smoke Sensor, press the small Test button located on the front cover for at least 30 seconds
If the Smoke Sensor test is successful, the LCD screen will display "Sensor xxx Passed." If these words do not appear, return
to "Add the Smoke Sensor to the LifeShield System."
[www.LifeShield.com]

Installing the Smoke Sensor

I N S T A L L I N G Y O U R S E C U R I T Y S Y S T E M
i
It is important to follow the
manufacturer's printed instructions
regarding placement of the device
(location), installation (mounting)
and battery activation (including
removal of the battery tab insulator
paper) prior to moving on to the
next step involving integration of
this device with your LifeShield
system.
i
NOTE: If you require additional
assistance with setup or
installation, please contact
LifeShield Customer Support at
1-888-392-2044.
