LifeShield Home Security Quick Setup Manual page 57

Installing the Flood (Water) and Temperature Sensor
Add the Sensor to the LifeShield System
Once the Temperature and Flood (Water) and Temperature Sensor is installed it must be "added" to the LifeShield system in order to
function. You will need a Handset or Console to add it.
Enter the Security menu on the Handset (or Console)
1. On the Handset or Console, Press MENU
2. Scroll to Security Setup, press SELECT and enter the Master Code
3. Scroll to Sensors, press SELECT
4. Scroll to <Add New>, press SELECT
5. Scroll to Environmental, press SELECT
6. Following the instructions displayed on the Handset or Console, wait 5 seconds, then press and release the red
tamper switch button on the wireless transmitter (see illustration)
Once the Sensor has been added to the LifeShield system:
7. Use the Edit feature to rename the device (optional). Press DELETE to erase text and use the keypad to type
in a new name. Once you are satisfied with the entered name, press OK
8. Scroll down to select the type of condition to which this Sensor will be associated (Flood, Cold, Warm or Hot)
and press SELECT
9. Press OK to return to the Main Menu
10. Position the top cover in place over the wireless transmitter and snap it into place, being careful not to pinch or cut
the wires leading to the Water Probe (if the Sensor is set up for Flood detection)
Testing as a Flood (Water) Sensor
1. On the Handset or Console, Press MENU
2. Scroll to Utilities, press SELECT
3. Scroll to Test, press SELECT
4. Enter your Master Code
5. Select System Test
6. Press the SKIP soft key to skip the Siren Test
7. Press the OK soft key on next screen for Starting Comm Test
8. Scroll to the name of the Sensor that you would like to test, and
press SELECT
9. Place the Water Probe directly into water (or alternately place a piece of
wet cloth between the probe legs) and wait at least three (3) minutes
If the Sensor test is successful, the LCD screen will display "Sensor xxx
Passed." If these words do not appear, return to "Add the Sensor to the
LifeShield System."
NOTE: If you require additional assistance with setup and installation please
contact LifeShield Customer Support at 1-888-392-2044.
[37]
I N S T A L L I N G Y O U R S E C U R I T Y S Y S T E M
Testing as a Temperature
(Hot, Cold, Warm) Sensor
The temperature sensing aspects of the Honeywell Model 5821 can be tested
in the same manner as above with the use of specialized equipment that is
capable of increasing or lowering the ambient temperature in the
environment surrounding the Sensor (as needed to result in activation).
