Installing the Camera
Install the Camera
Home Ethernet Network
a) First Camera
1. Plug one end of the supplied Internet cable into the receptacle labeled "LAN"
on the back of the Camera. Plug the other end either directly into your router
or into an available home Ethernet wall plate receptacle
2. Plug the supplied AC power adapter into the port on the back of the
Camera labeled "Power." Plug the other end into an available AC
power outlet
3. Follow the steps in "Add the Camera to the LifeShield System" section of
this guide
b) Second, third and fourth Camera: Repeat the steps above for each additional
Camera, making sure to add one camera at a time.
Powerline Adapter Network
a) Install Powerline Adapter at the home router/modem.
1. Plug a Powerline Adapter into an available AC wall outlet close to the
router/modem
2. Connect one end of the Internet cable (supplied) into the bottom of the Pow-
erline Adapter and the other end into an available port on your router/modem.
b) First Camera
1. Choose the location for the Camera (must have an AC wall outlet nearby with
two (2) available receptacles)
2. Plug one end of the supplied Internet connection cable into the port labeled
"LAN" on the back of the Camera. Plug the other end into the bottom of the
nearby Powerline Adapter
3. Plug the supplied AC power adapter into the port on the back of the Camera
labeled "Power." Plug the other end into the AC wall outlet
c) Second, third and fourth Camera: Repeat Step b above for each additional
Camera, making sure to add one Camera at a time.
[39]
I N S T A L L I N G Y O U R S E C U R I T Y S Y S T E M
Router/Modem
Home AC Wiring
