LifeShield Home Security Quick Setup Manual page 60

Add the Camera to the LifeShield System
The HomeView Camera(s) must be sequentially "added" to the LifeShield system in order to
function. You will need a Handset or Console to add your Camera(s).
1. On the Handset or Console, Press MENU
2. Scroll to Cameras, press SELECT and enter Master Code
3. Scroll to <Add New>, press SELECT and follow the steps displayed on the LCD screen
The LifeShield system will automatically search your home network for the newly added
Camera(s). As it finds the newly added Camera you will be prompted to name it, then
press OK
To edit the Camera name (optional) press DELETE to erase text and use the keypad to type in
a new name. Once you are satisfied with the entered name, press OK
How to Reset the Camera
If for any reason the LifeShield system is not able to connect to the Camera, resetting the
Camera to factory defaults and re-adding it may solve the problem. To reset the Camera,
locate the "RESET" button hole on the bottom right side of the Camera. Insert a paperclip to
depress the button and hold it there for at least 10 seconds (until the green Power and
Network LEDs remain on solidly), then release it. This will start the Camera's automatic reset
process. Wait at least 30 seconds then try re-adding it to the LifeShield system.
[www.LifeShield.com]
Installing the Camera
I N S T A L L I N G Y O U R S E C U R I T Y S Y S T E M
i
NOTE: Before adding a Camera,
make sure that the green
"Power" LED is solidly lit,
indicating it is ready to be added.
t
INSTALLATION TIP - If you have
physically connected all Cameras
to the network before Step 3 you
will need to add them one at a
time by returning to <Add New>
until all Cameras are found and
added. In this case it is better to
wait until all Cameras are
"added", then change the names
afterwards. Once they are added
you can view and rename them
using LifeShield.com
[40]
