This section provides descriptions and diagrams of each of the main LifeShield Home Security system components, along
with a listing of controls and functions.
Base Controls and Functions
The Base is one of three Grid Controllers (GCs) — Base, Console and Grid Extender — that communicate with each other
and with the Sensors in its coverage area. The Base also communicates with the Handset.
The Base provides your LifeShield Home Security system's broadband interface.
1. Handset Cradle – Handset charges while in the cradle
2. Charging LED – Illuminates amber when Handset is properly seated in the cradle for charging
3. Armed Status LED – Illuminates red when system is armed
4. Page Button – Activates audible tone on Handsets for locating
[www.LifeShield.com]
4
3
Figure 15. Base - Front View
Base Controls and Functions
1
2
U S I N G Y O U R S E C U R I T Y S Y S T E M
i
The Base should be located
where you have a Modem/Router
for Internet connectivity.
The Base has a charging cradle
which can be used as an
alternative to the Handset
charging cradle.
The Base includes battery
backup for continued operation
during power outages.
!
Always ensure that your GCs are
plugged into an electrical wall
outlet that is not controlled by
a switch.
[42]
