Console Telephone Controls and Features
Figures 48 and 49 highlight the telephone-specific functions located on both your Console and Handset.
8 9
7
6
5
4
3
2
Figure 48. Telephone Features on the Console
1. Scroll Button (Up/Down) – Navigates menus, adjusts volume, accesses recent calls
2. * - Pressing * in recent call list adds a 1 for long distance
3. # - Telephone answering system access (retrieving messages)
4. PAGE – Activates audible tone on Handsets for locating
5. MUTE – Mutes phone microphone
6. TALK/END – Initiates/ends calls and provides menu exit
7. Message LED – Indicates new message waiting
8. Soft Key – Changes functions based on menu navigation; active function shown on display above key; Main Display – PHNBK function retrieves
phone book entries
9. Soft Key – Changes functions based on menu navigation; active function shown on display above key; Main Display – MENU function allows menu
navigation
