Before connecting the device, please read and follow the installation
instructions. Failure to do so could cause equipment failure; Amano
is not responsible for any damages.
Please use the enclosed cable [either 6ft Ethernet, or 50 ft USB-to-
Serial cable to connect the FPT-40 Fingerprint terminal. If longer
serial cables for direct connect are required please consult Amano.

Understanding the FPT-40 Fingerprint Terminal Front Panel

The front panel of the FPT-40 Fingerprint terminal (see Figure 1-1)
contains the following controls:
LEDs: During normal standby operation (power on), the
LED will flash once per second, and stay on momentarily when a
user successfully verifies. If a user fails to verify, the
momentarily stay on.
Note: If the fingerprint reader does not follow the standard LED
operational parameters, please consult support.
Speaker: Provides audible voice verification of operations, i.e.,
"Thank you", "Incorrect Password", "Access Denied", "Invalid Id",
"Please try again", etc. See Advanced Options on page 2-41 for
voice control.
LCD Screen: Displays time, date, day, and operational information.
Fingerprint Sensor: Enrolls (creates) template and verifies
fingerprint.
Keypad: Used to input User ID, password, and perform menu
operation with the following keys:
ESC – to perform exit, cancel, ignore when using the Menus.
MENU – to access Menu structure.
OK – to confirm and/or save selection.
-
power ON/OFF button.
or - to scroll down or up for menu operations.
Note: Press the Power ON/OFF
Page 1-4 FPT-40 Fingerprint Terminal Installation & Operation Guide
button to turn off the terminal.
Green
Red LED will
