How to Enroll a User with a Password

To enroll at the FPT-40 terminal with a password perform:
1. Press the Menu button to display the main menu (see figure), or
display "Admin Affirm 1" and login with privileges.
2. Press OK to display the User Manage menu (see figure).
3. Press OK to display the Enroll User menu and select Enroll Pwd
(see Figure 2-24).
4. Press OK and Enroll Pwd New Enroll? will appear (see Figure 2-25).
Figure 2-25 New Enroll Pwd Screen
Page 2-14 FPT-40 Fingerprint Terminal Installation & Operation Guide
Menu
User Manage
Options
Sys Info
Figure 2-22 Menu Screen
User Manage
Enroll User
Enroll Admin
Delete
Figure 2-23 User Manage Menu
Enroll User
Enroll FP
Enroll Pwd
FP & Pwd
Figure 2-24 Enroll User Menu
Enroll Pwd
New Enroll ?
ESC OK
