3. Press OK to display the Comm Opt menu (see Figure 2-111).
4. Press " / " to scroll up or down to select the desired option. Press
OK and use the numeric keypad and/or " / " to enter the desired
value. For all Comm options, pressing ESC will return to the Comm
Opt menu with the default value/state.
Follow this example to enter the IP Address:
1. From the Comm Opt menu, select IP Addr [IP address] (see figure)
and press OK.
Figure 2-112 Comm Opt Menu – IP Addr
2. Enter the desired IP address (see Figure 2-113) by using " / " to
move forward or backward and the keypad to enter a number.
FPT-40 Fingerprint Terminal Installation & Operation Guide
Comm Opt
BaudRate
Dev Num
IP Addr
Net Speed
NewMask
Gateway
Ethernet
RS232
Rs485
COMM Key
Figure 2-111 Comm Opt Menu
Comm Opt
BaudRate
Dev Num
IP Addr
IP Addr
192. 168. 1. 201
ESC
Figure 2-113 Enter IP Address
115200
1
N
AUTO
Y
Y
N
0
115200
1
1
OK
Page 2-47
