Follow this example to set the shutdown time:
1. Press OK from the Power Mng menu, with Shutdown selected
(see figure).
Figure 2-107 Select Shutdown Time
2. Press OK to enter shutdown time of day in 24 hour format (see
Figure 2-108). Use " / " to move between hours and minutes and
the keypad to enter time.
3. Once the desired shutdown time of day in 24H format is set, press
OK to exit and display the Power Mng menu (see Figure 2-106).

Communications Options Menu

Use the Comm Opt menu at the FPT-40 terminal to set:
BaudRate: The default is "115200". The five (5) communications
speed options are; 115200, 57600, 38400, 19200, and 9600. The
value must be set consistent with the communications ports of the
Time Guardian host PC.
Dev Num: The default is "1". The range is 1 to 255. The device
number is unique for each terminal. If there are two terminals with
the same number in the network, they will not work properly and
Time Guardian will be confused when polling the terminals.
IP Addr: The default is "192.168.1.201". The IP address for the
terminal must be unique in the LAN.
FPT-40 Fingerprint Terminal Installation & Operation Guide
Power Mng
Shutdown
PowerOn
Sleep
Power Mng
Shutdown
PowerOn
Sleep
Figure 2-108 Shutdown Screen
N
N
N
23 : 59
N
N
Page 2-45
