3. Once the correct IP address is entered, press OK to save, or ESC to
exit with the default IP address [192.168.1.201].

Log Options Menu

Use the Log Opt menu at the terminal to:
Alm SuperLog: The default is "99". The range is 0 to 99. When the
supervisor capacity log numerical value is reached, an alarm will
sound to automatically indicate that the logs are full.
Alm AttLog: The default is "99". The range is 0 to 99. When the
attendance log capacity numerical value is reached, an alarm will
sound to automatically indicate that the logs are full.
ReCheck Min: The default is "0". Each unit = a minute, i.e., 2 = 2
minutes. This feature is dissabled when set to 0. Recommended
setting is 1 or 2 minutes. This feature provides repunch protection.
For example, when set to 1 minute, if an employee punches multiple
times at the terminal within the 1 minute, only the first punch will be
recorded in flash memory. All verified additional punches within the
ReCheck Min setting will be follwed by the voice prompt, "Punch
accepted....thank you".
To set Log Options:
1. Press the Menu button and select Options (see figure).
2. Press OK to display the Options menu and select Log Options
(see Figure 2-115).
Page 2-48 FPT-40 Fingerprint Terminal Installation & Operation Guide
Menu
User Manage
Options
Sys Info
Figure 2-114 Select Options
Options
Power Mng
Comm Opt
Log Opt
Figure 2-115 Select Log Opt Menu
