FLASH Test

This will test the flash memory in the FPT-40 Fingerprint terminal and
indicate the functional status. Select the FLASH test, and press OK to
run (see figure).
Note: Once this test is started do not interrupt the power as this could
cause damage to the internal flash memory.
The test will display Finished! if the flash memory is good (see figure).
Press OK or press ESC to return to the Auto Test menu.

LCD Test

This diagnostic tests the display by turning on all the pixels. Any spots
would indicate a defective pixel.
Press OK to complete each phase of the test, or press ESC to exit the
test and return to the Auto Test menu.
FPT-40 Fingerprint Terminal Installation & Operation Guide
FLASH Test
Pls Keep Pwr On
Continue?
ESC
Figure 3-6 FLASH Test
FLASH Test
Finished !
All : 31 Bad : 0
ESC
Figure 3-7 FLASH Test Finished
OK
OK
Page 3-3
