Amano Time Guardian FRT-40 User Manual page 33

3. Press OK to display the Enroll User menu and select Enroll Pwd
(see Figure 2-35).
4. Press OK and Enroll Pwd New Enroll? will appear (see Figure 2-36).
Figure 2-36 Enroll Pwd New Enroll Screen
5. Press ESC to change the password, and Chg Password User ID will
appear to accept/enter the User ID (see figure). Use the keypad
and/or the or
to exit and return to the Enroll User menu.
Note: If an unknown User ID is entered, the warning "No Enroll!" will
appear.
Figure 2-37 Change Password Select User ID
Page 2-18 FPT-40 Fingerprint Terminal Installation & Operation Guide
Enroll User
Enroll FP
Enroll Pwd
FP & Pwd
Figure 2-35 Enroll User Menu
Enroll Pwd
New Enroll ?
ESC
buttons to select the desired User ID. Press ESC
Chg Password
UserID 00001
ESC
OK
OK
