3. Press OK to display the Log Opt menu (see Figure 2-116).
4. Select the desired option. For log options, press OK and use the
numeric keypad and/or " / " to enter/select the desired value (see
figure for example). For all Log options, pressing ESC will return to
the default value/state and exit to the Log Opt menu.
Follow this example to enter the ReCheck Min:
1. From the Log Opt menu, select ReCheck Min (see figure), and press
OK.
Figure 2-117 Log Opt Menu – ReCheck Min
2. Enter the ReCheck Min time (see Figure 2-117) by using the " / "
buttons or the keypad to move between minutes [the range is 0 to
99] for time entry.
3. Once the desired ReCheck Min is set, press OK to save and return
to the Log Opt menu.

Auto Test

This option is designed to run assorted tests on the unit to analyze a
failure for quick and easy maintenance. These tests check such things
as the memory, LCD display, sound, fingerprint sensor, keypad, and
clock. During these tests the power should be maintained to prevent any
hardware damage; especially during the memory test. See Diagnostics
on page 3-1 for additional information and operational details.
Note: if any users have been setup with privileges, you must be a user
with Admin privileges to have access to the Auto Test menu.
FPT-40 Fingerprint Terminal Installation & Operation Guide
Log Opt
Alm SuperLog
Alm AttLog
ReCheck Min
Figure 2-116 Log Options Menu
Log Opt
Alm SuperLog
Alm AttLog
ReCheck Min
99
99
0
99
99
0
Page 2-49
