3. If you selected Network as the Connection Type for your FPT-40
Fingerprint terminal, enter the IP Address in the spaces provided.
IP Address: The IP Address of the terminal(s). You may have to
obtain this from network administrator. see Communications Opt
for default Ethernet address and configuration at the terminal.
Time Zone Offset: This can be used if your PC and the
Location (terminals) are located in different time zones. The
default value is 0:00. Use the dropdown lists to configure the
offset.
Active: When checked, the Location will begin sending and
receiving data.
Note: During TG installation and using the Setup Wizard, an Ethernet
connected Fingerprint terminal will not be auto-detected.
4. After you entered the correct information, click on the Save button.
The new Location Name will appear in the Location List. To clear
any terminal information entered in the Time Guardian
Communications Settings, click on the Cancel button.
To delete a Location, select the desired Location from the Location
List and click on the Delete button. A message will appear to
confirm your selection.
5. To exit the Time Guardian Communication Settings dialog, click on
the Close button to return back to the Time Guardian main screen.

Assignments Tab - Clock

The Assignments tab in Time Guardian (see figure) can be used to
manually assign employees/users to a terminal or a group of terminals. If
employees' records already exist in the database, polling a terminal will
automatically create employee terminal assignments.
FPT-40 Fingerprint Terminal Installation & Operation Guide Page 4-5
