Amano Time Guardian FRT-40 User Manual page 26

3. Press OK to display the Enroll User menu and select Enroll FP
(see Figure 2-15). The possible enrollment choices using the
buttons are; FP = fingerprint, Pwd = password only, and FP &
Pwd = fingerprint & password).
4. Press OK and Enroll FP New Enroll? will appear (see Figure 2-16).
Note: If this is the first User ID the display will show "New Enroll User
ID 00001". Pressing ESC at this step will place the terminal into
the Backup Enroll mode (see How to Enroll Multiple Fingers for a
User on page 2-23).
5. Press OK to begin enrollment, and New Enroll User ID will appear to
accept/enter the User ID (see figure). Enter the User ID using the
keypad and/or the
the Enroll User menu.
Figure 2-17 New Enroll User ID Screen
Note: The default User ID is 5 digits, so any number less than 5 digits
will have zeros in front of it, i.e., if the number is 2, 00002 will be
displayed. The User ID will auto-sequence each new User ID + 1
digit. [the range is 00001 to 65534].
FPT-40 Fingerprint Terminal Installation & Operation Guide
Enroll User
Enroll FP
Enroll Pwd
FP & Pwd
Figure 2-15 Enroll User Menu
Enroll FP
New Enroll ?
ESC
Figure 2-16 New Enroll FP Screen
or buttons. Press ESC to exit and return to
New Enroll
User ID 00002
ESC
OK
OK
or
Page 2-11
