Net Speed: The network default speed is "AUTO". The other
choices are: 10M-H, 100M-H, 10M-F and 100M-F.
Net Mask: The default is "255.255.255.0". The subnet mask must
be consistent to the LAN IP address of the device.
Gateway: The default is "0.0.0.0". If Gateway and Net Mask are not
defined, Ethernet will not be active.
Ethernet: select "Y" or "N" for Ethernet TCP/IP communications.
This option must be set to (Y)es to utilize Ethernet.
RS232: select "Y" or "N" for RS232 serial communications.
RS485: select "Y" or "N" for RS485 serial communications
[used for transmission distances over 50 feet].
COMM Key: The default is "0". The range is 1 to 999999. This
function is not used.
To set communication options:
1. Press the Menu button and select Options (see figure).
2. Press OK to display Options menu and select Comm Opt
(see Figure 2-110).
Page 2-46 FPT-40 Fingerprint Terminal Installation & Operation Guide
Menu
User Manage
Options
Sys Info
Figure 2-109 Select Options
Options
System Opt
Power Mng
Comm Opt
Figure 2-110 Select Comm Opt
