Amano Time Guardian FRT-40 User Manual page 41

7. Follow the on screen prompts for a total of 3 finger presses to add
the finger template, or press ESC to return to the Enroll User menu.
Press OK to save the 2
digit User ID followed by a "dash 1" (see figure).
8. Press OK, to continue with Backup Enrollment (see figure), or press
ESC to discontinue the Backup Enrollment process and return to the
Enroll User menu.
Figure 2-62 Backup Enroll Continue
9. The current numeric User ID will be shown first, and the User IDs will
be listed in ascending numeric order. Use the keypad and/or the
or buttons to enter/select the User ID you want to add a finger
template to, and press OK. See Step 6 to continue with the backup
enrollment process. Press ESC to abort the process and return back
to the Enroll User menu.
Figure 2-63 Backup Enroll Continue with User ID
Page 2-26 FPT-40 Fingerprint Terminal Installation & Operation Guide
nd
finger template which is indicated by the 5-
Backup Enroll
00001-1
ESC
Figure 2-61 Backup Enroll User ID
Backup Enroll
Continue?
ESC
Backup Enroll
Continue?
User ID 00001
ESC
OK(Save)
OK
OK
