- Page 1 OPUS-4000 Exit Terminal Distributor’s Manual OPUS4000_Distributor_04162015...
- Page 2 Roseville, Minnesota 55113 Notice of Liability: Amano makes no representations or warranties with respect to the accuracy or completeness of the contents of this work and specifically disclaim all warranties, including without limitation, warranties of fitness for a particular purpose. Amano reserves the right to make equipment changes and improvements that may not be reflected in this document.
-
Page 3: Table Of Contents
4.4 Backing Up and Restoring Data............18 4.5 Viewing Exit Terminal Logs............... 18 4.6 Backing Up Data Before Moving the SD Card......... 19 4.7 Restoring SD Data After Replacing the SD Card......19 OPUS-4000 BOOT MODES................. 19 © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 4: Introduction
The OPUS-4000 Series Exit Terminal utilizes innovative technology and an encrypted 2D data matrix barcode for expedited exit from parking facilities. The OPUS-4000 Series offers intuitive user guidance through a dynamic color display and voice announcement. The Exit Terminal processes encrypted thermal 2D barcode tickets from the OPUS-2000 Series Entry Terminal. -
Page 5: Initial Operation
Once all desired changes have been made, accept the current date and time by pressing Chan Down. If Chan Down is not pressed, the changes are not saved. Press the Power button to return to page two of the Initial Operation menu. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 6: Check For Errors And Warnings
Vol Up for the next errors. 1.5 Check the Data Printed on an Entry Ticket The OPUS-4000 has the ability to read and display the data printed on OPUS- 2000 entry tickets. To read the data on a ticket, enter the Initial Operation menu by pressing Chan Up on the remote. -
Page 7: Clearing The Management Password
PERATION The Management Operation menu contains configurable items for managing OPUS-4000 operations. The configurable items are exit mode, timers, store validation coupons, special days and periods, closed days, in-operation time, backlight settings, volume switch settings, exit warning, and password settings. -
Page 8: Changing The Exit Mode
Once the desired number is entered, press Chan Down. Scroll through the other timers using the Vol Up and Vol Down buttons on the remote. Press Power once all information is entered. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 9: Adding Store Validations
If the special day falls on a Sunday and the special day is observed on a Monday, press the designated number beside the special day to Not slide if it is Sunday. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 10: Special Period
Select a day to close by pressing the number on the remote designated by the number beside the day. The O is changed to an X for the selected day. [Fig. 3.5B] Closed days are designated by an ‘X’ © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 11: In-Operation Time
Press Power after the desired changes have been made. 3.7 Backlight Time Activation The OPUS-4000 backlight may be activated at a user-specified Start and End time. To navigate to the Backlight Setting menu, open the Management Operation menu and press 9. To activate the Backlight ON/OFF Time setting press 1. -
Page 12: Volume Switch
Add a new staff member by pressing the number on the remote designated by the number beside the Stf.No. Once in the second Password Setting menu, press 1 to add a password for the staff member. Enter a password and press © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 13: Engineer Operation
Restore All. Press Chan Down to confirm the parameter restore, or Mute to cancel the restore. Once the restore is complete, the window will display a Return button. Press Chan Down to return to the Parameter Setting menu. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 14: Common Parameters
If exiting out of the Parameter Setting menu, a pop-up window will display explaining the Terminal must be restarted to activate the change(s). Power cycle the Exit Terminal to make the change. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 15: Specific Parameters
Please adjust the parameters to the facility’s needs, and press Power when finished. If exiting out of the Parameter Setting menu, a pop-up window will display explaining the Terminal must be restarted to activate the change(s). Power cycle the Terminal to make the change. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 16: Select Function
Once the language is selected, press Chan Down to confirm the selection. After the desired languages are selected, register the selections by pressing Chan Down. Confirm the changes by pressing Chan Down once more in the pop-up window. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 17: Testing Exit Terminal Functions
Chan Down to confirm clearing all counts. Scroll through the functions using the Vol Down and Vol Up buttons. Once finished viewing the counts, press Power to return to the Engineer Operation menu. © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 18: Backing Up And Restoring Data
The logs available for the Exit Terminal are: • Exit Data • Error Data • Alarm Data • Monitor Data • Operation Monitor • Power ON/OFF • Payment • Unsent Record Count • Error List • Online Data © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015... -
Page 19: Backing Up Data Before Moving The Sd Card
Engineer Operations menu and press 9. Press Chan Down to confirm the restore. ODES The OPUS-4000 contains a bank of dip switches on the iCore board responsible for determining the boot mode and/or logging. Please use the images below to select the proper dip switch settings. - Page 20 OPUS-4000 Distributor’s Manual © Copyright 2014 Amano McGann, Inc. OPUS4000_Distributor_04162015...
