Specifications (Cont.)
Memory Backup:
Display:
Keypad:
Clock:
* Specifications and/or operational characteristics are subject to change without notice. The
AC adapter is UL listed E215890.

Installation

Unpacking Fingerprint Terminal/Time Guardian Package

In addition to this guide, your package should include the following:
Fingerprint Data Collection Terminal
AC Adapter
USB-to-serial connector (RJ-11) with 50ft cable
6 foot Ethernet cable
Terminal mounting plate and hardware
Time Guardian Software Installation Manual
Time Guardian CD
Spare sensor lens/prism (see Replacing Optical Sensor Lens).
Locate this item and store in a safe place for possible
future use!! DO NOT DISCARD.

Before Installing FPT-40 Fingerprint Terminal

Before installation, please make sure the unit is not connected to
power. Connect the power to the unit as the last step.
The recommended proper height to mount the device is 55 – 60 "
(1.4 – 1.5 meters).
Use only the AC adapter provided. Use of another AC adapter may
damage the unit and void the warranty.
FPT-40 Fingerprint Terminal Installation & Operation Guide
Provides up to 3 years of continuous memory
backup without AC power.
2.8" diagonal, 128 x 64 dots resolution LCD
reflective (backlight).
4x4 keypad (0~9, OK, ESC) + 4 function keys.
Quartz oscillator, accuracy within
per week at normal temperature.
3 seconds
Page 1-3
