BATTERY CHARGING
D Regular charging with the BC-171
The optional BC-171 provides regular charging of the Li-ion battery
pack.
Charging period: Approximately 4 hours (with BP-230N)
The following items are additionally required:
• An AC adapter (not supplied with some versions) or the DC power
cable (OPC-515L/CP-23L) is additionally required.
AC adapter
(A different type, or no AC adapter is
supplied, depending on the version.)
Optional OPC-515L*
(for power source) or
CP-23L (for 12 V ciga-
rette lighter socket)
can be used instead
of the AC adapter.
*
About OPC-515L
White line:
Black line :
22
IMPORTANT!
Ensure the guide tabs on the
battery pack are correctly
aligned with the guide rails
inside the charger adapter.
Transceiver
Battery pack
Guide rail
Turn power OFF
Tabs
