Network 2 (wwan0)
SMS Outbound Settings
Test Phone Number
Test Message Body
Send Test Message
(button)

To Configure Network 2 SMS Outbound Settings

Using Web Manager

To modify Network 2 SMS Outbound settings, click Network on the menu bar and select
Network 2 → Configuration → SMS Outbound
Using the CLI

To enter the Network 2 SMS outbound command level:
enable -> config -> if 2
Using XML

Include in your file:

Network 2 SMS Inbound Settings

This device will accept inbound SMS messages and perform specific actions based on the
message content. Currently this device allows SMS messages to control the relay states: Open or
Close. The SMS Inbound message content is checked against configured strings associated with
relay output actions: Open or Close. When there is a match, the relay action is performed.
For added security, the SMS Inbound feature supports configuration of a whitelist, of up to 5
phone numbers from where it will accept messages.
All SMS Inbound messages will be discarded if the SMS Inbound State is Disabled or the phone
number is not configured in the Received Number list.
The table below shows the settings for SMS Inbound, and Received Number whitelist.
PremierWave XC User Guide
Description
Input the test recipient's phone number.
Input the Test Message Body.
Note: SMS Format is to be accordingly to the Message Body.

When Text ASCII is selected
(7 bit characters and typically limited to 160 characters per message.)

When Binary is selected
(8 bit characters and typically limited to 140 characters per message.)

When Unicode is selected
(16 bit characters and typically limited to 70 characters per message.)
Click to send out Test SMS Message
Note: This will test the SMS Outbound configured settings with the test phone
number and test message body.
->link -> sms outbound
<configgroup name="sms outbound">
