HTTP Settings
Logging State
Max Log Entries
Log Format
Authentication Timeout

To Configure HTTP Settings

Using Web Manager

To configure HTTP settings, click HTTP in the menu bar and select Configuration.

To view HTTP statistics, click HTTP in the menu bar and select Statistics.
Using the CLI

To enter the HTTP command level: enable -> config -> http
Using XML

Include in your file: <configgroup name="http server">
HTTP Authentication
Settings
URI
PremierWave XC User Guide
Description
Select Enabled or Disabled for the state of the HTTP server logging.
Sets the maximum number of HTTP server log entries. Only the last Max Log
Entries are cached and viewable.
Set the log format string for the HTTP server. Follow these Log Format rules:

%a - remote IP address (could be a proxy)

%b - bytes sent excluding headers

%B - bytes sent excluding headers (0 = '-')

%h - remote host (same as '%a')

%{h}i - header contents from request (h = header string)

%m - request method

%p - ephemeral local port value used for request

%q - query string (prepend with '?' or empty '-')

%t - timestamp HH:MM:SS (same as Apache '%(%H:%M:%S)t' or
'%(%T)t')

%u - remote user (could be bogus for 401 status)

%U - URL path info

%r - first line of request (same as '%m %U%q <version>')

%s - return status
The timeout period applies if the selected authentication type is either Digest
or SSL/Digest. After this period of inactivity, the client must authenticate
again.

Table 9-5 HTTP Authentication Settings

Description
Enter the Uniform Resource Identifier (URI).
Note: The URI must begin with '/' to refer to the filesystem.
9: Services Settings
64
